8ʺ Smart Dual Flashing Beacon Sign

The leading cause of roadway accidents in North America is distracted driving. The addition of dual flashing beacons will help prevent accidents in critical areas such as intersections, crosswalks and school zones by attracting attention to traffic signs. With high-intensity LED lights, the single flasher beacon catches the drivers’ attention and ensures the visibility of signs, thus improving road safety.

8ʺ Smart Dual Flashing Beacon Sign - LED Traffic sign - THIN - Traffic Innovation
Icon of reinforces the sign in critical zones - Traffic Innovation

REINFORCES THE SIGN IN CRITICAL ZONES

Icon of solar power supply - Traffic Innovation

SOLAR POWER SUPPLY

Icon of increases road users safety - Traffic Innovation

INCREASES ROAD USERS' SAFETY

Icon of low installation costs - Traffic Innovation

LOW INSTALLATION COSTS

8ʺ Smart Dual Flashing Beacon Sign - Electronic Traffic Sign - THIN - Traffic Innovation
Vertical or horizontal installation - LED Traffic sign - THIN - Traffic-innovation

VERTICAL OR HORIZONTAL INSTALLATION

Three colors available - LED Traffic sign - THIN - Traffic-innovation

THREE COLORS AVAILABLE

Add a reflective or standard traffic sign - LED Traffic sign - THIN - Traffic-innovation

ADD A REFLECTIVE OR STANDARD TRAFFIC SIGN

Select flashing pattern - LED Traffic sign - THIN - Traffic-innovation

SELECT FLASHING PATTERN DIRECTLY ON THE PANEL

LED traffic sign operation modes - LED Traffic sign - THIN - Traffic-innovation

LED TRAFFIC SIGN OPERATION MODES

Power supply options - LED Traffic sign - THIN - Traffic-innovation

POWER SUPPLY OPTIONS

TECHNICAL SPECIFICATIONS OF THE DUAL FLASHING BEACON SIGN

Technical specifications of the dual flashing beacon sign - Traffic Innovation

Solar Power Unit (All-in-one)

Solar Panel: 30 W Monocrystaline
Battery: 12.8 V – 14 Ah – LifePo4
Solar Charger: MPPT, 10 A, IP67
Connector: 10 mm OD, Male, 6ʺ, IP67
Operating Temperature: -40 to +74ºC (-40 to +165ºF)
Weight: 7.7 kg (17 lb)

Dual Flashing Beacon Sign

Beacon Lens: Two (2x) 200 mm (8″) Amber or Red LEDs
Standard: ITE VTCSH-STD 2005
Auto-Brightness: Various Stages of Brightness for Day or Night (can be manually disabled)
Controller: Built-in
Controller Input Voltage: 9.6 to 14 VDC
Connector: Snap-in, Overmolded IP67 Connector, 10 mm OD
Flash Patterns: MUTCD (0.5 sec ON, 0.5 sec OFF), Solar Power Mode or Rapid Flash
Beacon Control: Wig-Wag or Simultaneous
Operation: 24 hrs, Night Only or Optional Activation
Operational Temperature: -40 to +74°C (-40 to +165°F)
Default: 24 hrs – Wig-Wag – Solar Power Flashing Pattern Mode (0.2 sec ON)
Reflective Sheeting: 3M High Intensity Prismatic D 4956-09 ASTM type IV
Sign: 3 mm (.125″) Aluminum 5052-H38
Visors: Aluminum, Textured Black Powder Coated
Lens: UV Stabilized Clear PVC
Environmental Protection: IP67

Product Number Description Box : Dimenson – Weight HSS Code
Assembly Kit
#37754 Dual Flashing Beacon Sign, amber, black background, 30 W solar power unit 28 x 54 x 8 in – 52 lbs 8530.90
#37755 Dual Flashing Beacon Sign, red, black background, 30 W solar power unit 28 x 54 x 8 in – 52 lbs 8530.90
#38184 Dual Flashing Beacon Sign, amber, yellow background, 30 W solar power unit 28 x 54 x 8 in – 52 lbs 8530.90
#38880 Dual Flashing Beacon Sign, amber, black background, AC/DC power converter 18 x 32 x 14 in – 32 lbs 8530.90
#38881 Dual Flashing Beacon Sign, red, black background, AC/DC power converter 18 x 32 x 14 in – 32 lbs 8530.90
#38882 Dual Flashing Beacon Sign, amber, yellow background, AC/DC power converter 18 x 32 x 14 in – 32 lbs 8530.90
Activation Options
#38129 Software for configuration or night only activation (USB Dongle + Software) Included in kit box N/A
#36463 Wireless and battery-free Remote Control (software kit required) Included in kit box N/A
#36900 Radar Vehicule Detector Activation (software kit required) Kit box (+ 2 lb) N/A

Included with beacon : Installation hardware for 2ʺ Telespar post, 2-3/8ʺ round pole, U-Post or street light pole. 760 mm (30ʺ) male/female extension.

Smart USB Dongle required to change beacon configuration. Two (2) year Limited Warranty against defects in workmanship and materials.
